Distribution of footprint and fluxes source area of rubber plantation in Hainan Island
-
摘要: 为分析影响橡胶林通量观测数据质量的因素,利用农业部儋州热带农业资源与生态环境重点野外试验站50 m高通量观测塔2010年12个月连续的通量观测资料,应用Schmid的FSAM(Flux-Source AreaModel)模式,分析不同大气条件下橡胶林通量足迹与源区分布特征。结果表明:(1)在大气不稳定状态时,通量各传感器测得的信息源区比大气稳定状态时源区面积相对较小;在相同贡献率水平下,大气稳定状态生长季节观测到的通量信息源区面积比非生长季节的信息源区面积大,大气不稳定状态非生长季节的通量信息源区面积比生长季节的信息源区面积大。(2)盛行风方向在110°～250°时,生长季大气不稳定情况下,通量测量的信息源区(P=80%)迎风方向范围在100～758 m之间,垂直于迎风方向范围在-251～251 m之间,非生长季大气不稳定情况下,迎风方向和垂直迎风方向的范围较均值略大些;生长季稳定条件下,迎风方向和垂直迎风方向的范围分别为173～1 858 m和-534～534 m,非生长季稳定条件下,迎风方向和垂直迎风方向的范围较均值略小些。(3)风向在0°～110°,250°～360°时,与盛行风方向上的通量信息源区面积相比,橡胶林大气处于稳定状态,其通量信息源区面积范围明显要高,但在非稳定大气状态时,二者相差不大。Abstract: In order to analyze and control the quality of the rubber plantation flux observation data,the FSAM model（Flux-source Area Model） was used to calculate flux footprint and source areas according to the continuous flux measurement with the open-path eddy covariance system on the 50 m tower of the Ministry of Agriculture Danzhou Key Field Station of Observation and Research for Tropical Agricultural Resources and Environments from Jan.1 to Dec.31,2010.The spatial representative of flux measurement of the rubber plantations in Hainan Island,the south of China,was explained.Source areas of rubber plantation were found smaller under the unstable than under the stable atmospheric stratification.The source areas were larger in the growing season than in the dormant season at the same contribution level for the stable stratification,but they were smaller under the unstable stratification.In the main wind direction of 110°—250°,the upwind range of source areas of the rubber plantation was 100—758 m,and the vertical upwind range was-251—251 m at a 80% contribution level under the unstable stratification in the growing season,whereas the upwind and vertical upwind ranges were slightly larger than those under the unstable stratification in the dormant season.The upwind and vertical upwind ranges of the source areas were 173—1858 m and-534—534 m,respectively under the stable stratification in the growing season,and they were slightly smaller than those under the stable stratification in the dormant season.In the wind directions of 0°—110° and 250°—360°,the upwind range of the source areas was larger under the stable stratification of the rubber plantation than but similar to those in the prevailing wind direction under the unstable stratification.
-
Key words:
- flux footprint /
- Flux-Source Area Model /
- source area /
- rubber plantation /
- Hainan Island
-
[1] SERGEJ S Z， IGOR N E.Similarity theory and calculation of turbulent fluxes at the surface for the stably stratified atmospheric boundary layer [J].Boundary-Layer Meteorology， 2007， 125: 193-205. [2] RANNIK U， KERONEN P， HARI P， et al.Estimation of forest-atmosphere CO2 exchange by eddy covariance and profile techniques [J].Agricultural and Forest Meteorology， 2004， 126: 141-155. [3] BALDOCCHI D D， HICKS B B， MEYERS T P.Measuring biosphere-atmosphere exchanges of biological related gases with micrometeorological methods [J].Ecology， 1988， 69: 1331-1340. [4] GOULDEN M L， MUNGER J W， FAN S W， et al.Exchange of carbon dioxide by a deciduous forest: response to interannual climate variability [J].Science， 1996， 271: 1576-1578. [5] RUNNING S W， BALDOCCHI D D， TURNER D， et al.A global terrestrial monitoring network， scaling tower fluxes with ecosystem modeling and EOS satellite data [J].Remote Sensing Environment， 1999， 70: 108-127. [6] CURTIS P S， HANSON P J， BOLSTAD P， et al.Biometric and eddy covariance based estimates of annual carbon storage in five eastern North American deciduous forests [J].Agricultural and Forest Meteorology， 2002， 113: 3-19. [7] GUAN D X， WU J B， ZHAO X S， et al.CO2 fluxes over an old， temperate mixed forest in northeastern China [J].Agricultural and Forest Meteorology， 2006， 137: 138-149. [8] GASHJ H C.A note on estimating the effect of a limited fetch on micrometeorological evaporation measurements [J].Boundary-Lay Meteorology， 1986， 35: 409-414. [9] HORST T W， WEIL J C.How far is far enough —the fetch requirement for micrometeorological measurement of surface fluxes [J].Journal of Atmospheric and Oceanic Technology， 1994， 11: 1018-1025. [10] HAENEL H D， GRBNHAGE L.Footprint analysis: a closed analytical solution based on height dependent profiles of wind speed and eddy viscosity [J].Boundary-Lay Meteorology， 1999， 93: 395-409. [11] BALDOCCHI D， FALGE E， GU L H， et al.FLUXNET: a new tool to study the temporal and spatial variability of ecosystemscale carbon dioxide， water vapor， and energy flux densities [J].Bulletin of the American Meteorological Society， 2001， 82: 2415-2434. [12] PASQUILL F， SMITH F B.Atmospheric Diffusion [M].U K: West Sussex Press， 1983: 142. [13] SCHMID H P.Source areas for scalars and scalar fluxes [J].Boundary-Layer Meteorology， 1994， 67: 293-318. [14] SCHMID H P.Experimental design for flux measurements: matching the scales of observations and fluxes [J].Agricultural and Forest Meteorology， 1997， 87: 179-200. [15] HORST T W.The footprint for estimation of atmosphere surface exchange fluxes by profile techniques [J].Boundary-Lay Meteorology， 1999， 90: 171-188. [16] KORMANN R， MEIXNER F X.An analytic footprint model for neutral stratification.Boundary-Lay Meteorology， 2001， 99: 207-224. [17] BALDOCCHI D.Flux footprints within and over forest canopies [J].Boundary-Lay Meteorology， 1997， 85: 273-292. [18] FLESCH T K.The footprint for flux measurements， from backward Lagrangian stochastic models [J].Boundary-Lay Meteorology， 1996， 78: 399-404. [19] LECLERCM Y， SHEN S H， LAMB B.Observations and large-eddy simulation modeling of footprints in the lower convective boundary layer [J].Journal of Geophysical Research Atmospheres， 1997， 102: 9323-9334. [20] [21] [22] [23] GRELLE A， LINDROTH A.Eddy-correlation system for long-term monitoring of fluxes of heat， water vapour and CO2[J].Global Change Biology， 1996， 2: 297-308. [24] AUBINET M， GRELLE A， IBROM A， et al.Estimates of the annual net carbon and water exchange of forests: the EUROFLUX methodology [J].Advances in Ecological Research， 2000， 30: 113-175. [25] WEBB E K， PEARMAN G I， LEUNING R.Correction of flux measurements for density effects due to heat and water vapour transfer [J].Quarterly Journal of the Royal Meteorological Society， 1980， 106: 85-100. [26] -
